Dome Arch Tunnel Greenhouse 200 Micron Plastic Film Greenhouse
Tunnel Greenhouse Product overview:
The arched greenhouse is an economical greenhouse, which is
welcomed by users with its beautiful arc shape and low cost. The
top of the arc-shaped room is beautiful and smooth, and the line of
sight is smooth.
The amount of structural steel is small and the thermal insulation
performance is good. The manufacturing cost is relatively low and
it is an economical greenhouse suitable for most regions. Double
membrane greenhouses are mostly used in northern areas, and single
membrane greenhouses are mostly used in southern areas.
Tunnel Greenhouse Features:
t can get the maximum light in the range of 0.4-0.7 microns in
visible light. After the membrane is inflated, it can form a thick
air bag, which can effectively prevent the loss of heat and the
intrusion of cold air. The use of double-layer inflatable membrane
can greatly improve the thermal insulation performance of the
greenhouse To save operating costs. The top of the covering
material is covered with polyethylene film, the outer layer is
protected against ultraviolet rays, and the inner layer is
anti-condensation; surrounding can be covered with polyethylene
film or polycarbonate sheet according to user needs.
Greenhouse Materials:
The main structure of the greenhouse is made of cold-rolled hot-dip
galvanized pipes, which are connected by hot-dip galvanized bolts
and have good corrosion resistance.
Greenhouse Main Configuration:
According to user requirements, it is equipped with internal and
external shading, skylight side window ventilation, water curtain,
fan cooling and other facilities.
Parameter:
| Description | Technical Data details |
Film Tunnel Greenhouse | Span Width(m): 6.0 ~ 12.0 |
| Bay Width(m): 0.8 ~ 2 |
| Roof Height(m): 2.8-4m |
| Skeleton Material: Hot digged galvanizing steel pipe |
| Covering Material: PE film (2 layers is possible) |
| Outside Insulation: high quality quilt |
| Support system: side ventilation system (by film rolling up
machine) |
| We can supply customized design just as per your requests! |
Greenhouse Advantage:
1. Large lighting area and uniform illumination
2. Long use time and high intensity
3. It has strong anticorrosion and flame retardancy
4. More than 90% light transmission without decay with time
Packing and Delivery
1. The products are usually tied with packing tape.The packaging
size and container capacity of the product are different from the
product specifications
2. Container transportation, according to your project request.
Production time usually costs 10-20 days.
Service
1. We can design the most suitable greenhouse for you according to
your local climate and your needs.
2. We will give you a detailed quotation, so that you can clearly
see the composition of the price.
3. We provide a 5-year warranty service for steel pipes and a
3-year warranty service for covering materials.
4. we have a professional construction design team, can give you
the production of detailed construction drawings, at the same time
to give you remote technical guidance.
5. We also cooperate with many agricultural factories to help you
with one-stop shopping.
