    Multi-Span Greenhouse High Tunnel 200 Micron Polyethylene Film Greenhouse

    Ask Lasest Price
    Brand Name : BAOLIDA
    Model Number : BLD-102
    Certification : ISO9001:2008
    Price : USD 2-6/sqm
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 500000 SQUARE METERS ONE MONTH
    Delivery Time : 7-28 WEEK DAYS
    • Product Details
    • Company Profile

    Multi-Span Greenhouse High Tunnel 200 Micron Polyethylene Film Greenhouse


    Plastic Multispan Greenhouse Covering 200 Micron Film Polyethylene


    Production


    The greenhouse is a greenhouse with the simplest structure, the lowest cost and the most convenient installation. The frame structure is the core structure of the tunnel greenhouse. It includes slots, doors, ridges, arches, end posts, etc. The single span is generally between 6 and 12 meters. Its advantages are the largest footprint, simple installation, strong durability and long service life. In addition, disassembly, installation and transportation are very convenient, so the cost is the lowest, but the most cost-effective.


    DimensionRelated data
    Length10-100m
    Width6-12m
    Top height2.8-4m
    Shoulder height1-1.5m
    Arch spacing1-1.5m
    Arch diameterφ20mm,φ25mm,φ32mm,φ48mm,φ60mm
    Arch thickness1.2mm,1.5mm,1.8mm,2.0mm,2.5mm
    Covering materialPE film,PC sheet,ploycarbonate sheet,PEP film
    Basic equipmentFramework,door,insect net,film
    FoundationInsert the arch into the ground
    Tube materialHot dip galvanized steel tubu
    Thickness of PE film120micron 150micron 200micron

    USE

    1. Vegetable cultivation

    2. Flower cultivation

    3. Fruits such as grapes, strawberries, watermelon, oranges etc.

    4. Forestry seeding cultivation, planting ornamental trees and shrubs.


    Advantages

    1. Simple structure: Galvanized steel framework+plastic film covering +side ventilation.

    2. Easily assembled: The prefabricated steel pipes can be easily connected with some fastenings.

    3. The large inner space is convenient for operation and maintenance.

    4. This tunnel greenhouse doesn't cost too much, you can make a high output with low input.

    5. Long life span: The steel structure of the greenhouse can be used for more than 10 years.


    Covering:

    1. Clear PE film as the covering material;

    2. Thickness is 0.15mm or 0.2mm;

    3. Cover the greenhouse with the film of 1 or 2 layers;

    4. Has the function of dust-proof and anti-dripping;


    Irrigation system


    The irrigation system is the most effective way of water-saving for drought and water shortage area at present.The irrigation system has two methods: drip irrigation and spray irrigation. You can choose different irrigation methods according to the characteristics of the crop and the local water source.


    The drip irrigation:


    Water pump 2.5kw, 50HZ,
    with filter and relative accessories like ball valve, tee and angle etc.
    Main water pipe 20m (could be adjusted as customer requirements )
    Main water pipe: Φ50mm PE material
    Inlet water pipe :Φ32mm PE material
    Distributive pipe: Φ32mm PE material
    Drip tape hole spacing is 30cm.
    One greenhouse has 5-8 columns drip tapes
